A208SYCB04 - TE Connectivity

A208SYCB04 Details

• Manufacturer Part Number:

  A208SYCB04

• Brand Name:

  Alcoswitch

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Actuator Finish:

  NICKEL

• Actuator Length:

  0.41 inch

• Actuator Type:

  STANDARD TYPE

• Body Breadth:

  11.43 mm

• Body Height:

  10.41 mm

• Body Length or Diameter:

  12.7 mm

• Bushing Diameter:

  0.249 inch

• Bushing Length:

  0.37 inch

• Bushing Type:

  1/4-40

• Center Contact Plating:

  GOLD

• Contact (AC) Max Rating R Load:

  .02A@20VAC

• Contact Current(AC)-Max:

  0.4 A

• Contact Current(DC)-Max:

  0.4 A

• Contact (DC) Max Rating R Load:

  .02A@20VDC

• Contact Function:

  ON-(ON)

• Contact Resistance:

  0.01 mΩ

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Dielectric Withstand Volts:

  1000 V

• Electrical Life:

  6000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Termination Type:

  SOLDER
