Please enter a minimum 3 letters or numbers
Technical Content
Part Image

A4407KLPTR-T - Allegro Microsystems

Description: Automotive Quad Output Regulator

Download A4407KLPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
A4407KLPTR-T - Allegro Microsystems - PCB symbol
click to zoom
PCB Footprints
A4407KLPTR-T - Allegro Microsystems PCB footprint - Other - Other - LP Package, 24-Pin TSSOP
click to zoom
3D Models
A4407KLPTR-T - Allegro Microsystems - 3D model - Other - LP Package, 24-Pin TSSOP
click to zoom

A4407KLPTR-T Details

  • Manufacturer Part Number:

    A4407KLPTR-T

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    7.7

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    36 V

  • Input Voltage-Min:

    5.5 V

  • Input Voltage-Nom:

    13.5 V

  • JESD-30 Code:

    R-PDSO-G24

  • JESD-609 Code:

    e3

  • Length:

    7.8 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    135 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Equivalence Code:

    TSSOP24,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.2 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK

  • Switching Frequency-Max:

    2200 kHz

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Width:

    4.4 mm

A4407KLPTR-T Frequently Asked Questions (FAQs)

  • A good PCB layout for the A4407KLPTR-T involves keeping the sense lines short and away from noise sources, using a ground plane to reduce EMI, and placing the device close to the motor to minimize wiring length and noise pickup.
  • The sense resistor value depends on the motor current and the desired current sense accuracy. A good starting point is to choose a sense resistor value that results in a sense voltage of around 50-100 mV at the maximum expected motor current.
  • The maximum allowable voltage on the VCC pin is 5.5V. Exceeding this voltage may damage the device.
  • The A4407KLPTR-T has built-in thermal shutdown and overcurrent protection. In the event of an overcurrent or overtemperature condition, the device will shut down and restart when the condition is cleared. The designer should ensure that the system can safely handle these events and provide adequate cooling and current limiting.
  • A 10-100 nF ceramic capacitor is recommended for VCC bypassing to filter out noise and ensure stable operation.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

A4407KLPTR-T Overview

Use the download button to access the A4407KLPTR-T schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like A4407, or try a keyword search, such as Switching Regulator or Controllers

Parts related to A4407KLPTR-T

Showing 0 results

Part Image

← Prev Next →
About Us Contact Us Terms of Service Do not sell or share my personal information Privacy Policy Digital Services Act Library Loader Twitter LinkedIn

All content Copyright © 2020, Supplyframe.com. All rights reserved. Back to top ↑
