A4935KJPTR-T - Allegro Microsystems

Description: Auto Three-Phase MOSFET Predriver

Download A4935KJPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A4935KJPTR-T - Allegro Microsystems PCB footprint - Other - Other - Package JP, 48-Pin LQFP
click to zoom
3D Models
A4935KJPTR-T - Allegro Microsystems  - 3D model - Other - Package JP, 48-Pin LQFP
click to zoom

A4935KJPTR-T Details

  • Manufacturer Part Number:

    A4935KJPTR-T

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    QFP

  • Package Description:

    LEAD FREE, MS-026BBCHD, LQFP-48

  • Pin Count:

    48

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    8
