A6216KLPTR-T - Allegro Microsystems

Description: Automotive 2A Buck Led Driver W/Internal PWM

Download A6216KLPTR-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A6216KLPTR-T - Allegro Microsystems PCB footprint - Other - Other - 16-Pin TSSOP (Suffix LP) with Exposed Pad
click to zoom
3D Models
A6216KLPTR-T - Allegro Microsystems  - 3D model - Other - 16-Pin TSSOP (Suffix LP) with Exposed Pad
click to zoom

A6216KLPTR-T Details

  • Manufacturer Part Number:

    A6216KLPTR-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    TSSOP-16

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Date Of Intro:

    2016-06-17

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    7.89

  • Interface IC Type:

    LED DISPLAY DRIVER

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    2

  • Multiplexed Display Capability:

    NO

  • Number of Functions:

    1

  • Number of Segments:

    2

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.2 mm

  • Supply Voltage-Max:

    55 V

  • Supply Voltage-Min:

    4.5 V

  • Supply Voltage-Nom:

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

A6216KLPTR-T Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the A6216KLPTR-T is -40°C to 150°C.
  • The VCC pin should be connected to a 5V power supply through a 10uF capacitor to ensure reliable operation and to filter out noise.
  • A recommended PCB layout for the A6216KLPTR-T includes keeping the device away from high-current carrying traces, using a solid ground plane, and minimizing the length of the traces connected to the device.
  • To troubleshoot issues with the A6216KLPTR-T, check the power supply voltage, ensure proper connections, and verify that the device is properly configured. Also, check for any noise or interference on the input signals.
  • Yes, the A6216KLPTR-T is AEC-Q100 qualified, making it suitable for use in automotive applications.
