AB-RTCMC-32.768KHZ-AIGZ-S7-T - ABRACON

AB-RTCMC-32.768KHZ-AIGZ-S7-T Details

• Manufacturer Part Number:

  AB-RTCMC-32.768KHZ-AIGZ-S7-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DLCC

• Package Description:

  3.20 X 1.50 MM, 0.80 MM HEIGHT, ROHS COMPLIANT, CERAMIC, LCC-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  7

• Clock Frequency-Max:

  0.032 MHz

• Information Access Method:

  SERIAL(I2C)

• JESD-30 Code:

  R-CDSO-N8

• JESD-609 Code:

  e4

• Length:

  3.2 mm

• Moisture Sensitivity Level:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  SON

• Package Equivalence Code:

  SOLCC8,.06,35

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.8 mm

• Supply Voltage-Max:

  4.4 V

• Supply Voltage-Min:

  1.3 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.9 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  1.5 mm

• uPs/uCs/Peripheral ICs Type:

  TIMER, REAL TIME CLOCK
