Abracon recommends a layout with a solid ground plane, minimal signal trace length, and a 10nF to 22nF decoupling capacitor between VCC and GND, placed as close as possible to the oscillator.
The oscillator is rated for operation up to 85°C, but its frequency stability may degrade above 70°C. For high-reliability applications, Abracon recommends derating the operating temperature to ensure optimal performance.
Yes, the oscillator is designed to minimize EMI emissions. However, to further reduce emissions, Abracon recommends using a shielded enclosure, minimizing signal trace length, and using a common-mode choke or ferrite bead on the output signal line.
The typical start-up time for the oscillator is around 2-5ms, but this can vary depending on the specific application and power supply conditions.
While the oscillator is a high-quality component, it is not specifically designed for safety-critical applications. Abracon recommends using oscillators with specific safety certifications (e.g., AEC-Q200) for such applications.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ABM12-30.000MHZ-B2X-T3 Overview
Use the download button to access the ABM12-30.000MHZ-B2X-T3 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ABM12,
or try a keyword search, such as Quartz Crystals
