ACJS-IH - Amphenol

ACJS-IH Details

• Manufacturer Part Number:

  ACJS-IH

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  7

• Audio Type:

  STEREO

• Body Breadth:

  0.618 inch

• Body Depth:

  1.173 inch

• Body Length:

  0.787 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  6.3MM AUDIO

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  10 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Insertion Force-Max:

  30 N

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED POLYAMIDE66

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of Connectors:

  ONE

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED KEY

• Rated Current (Signal):

  10 A

• Reference Standard:

  UL

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  10 N
