ACS110-7SB2 - STMicroelectronics

ACS110-7SB2 Details

• Manufacturer Part Number:

  ACS110-7SB2

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  PLASTIC, DIP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8541.30.00.80

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Additional Feature:

  WITH BUILT IN CLAMPING STRUCTURE AND GATE LEVEL SHIFTER DRIVER

• Configuration:

  SINGLE WITH BUILT-IN TRIGGER ELEMENT IN SERIES WITH GATE

• DC Gate Trigger Current-Max:

  10 mA

• DC Gate Trigger Voltage-Max:

  1 V

• JESD-30 Code:

  R-PDIP-T8

• JESD-609 Code:

  e3

• Leakage Current-Max:

  0.2 mA

• Non-Repetitive Pk On-state Cur:

  11 A

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -30 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• RMS On-state Current-Max:

  1 A

• Repetitive Peak Off-state Voltage:

  700 V

• Surface Mount:

  NO

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Trigger Device Type:

  SNUBBERLESS TRIAC
