ACS541KMSR-02 footprint, schematic symbol and 3D model by Renesas Electronics

ACS541KMSR-02 - Renesas Electronics

Description: The Intersil ACS541MS is a radiation hardened octal buffer/line driver, with three-state outputs. The output enable pins OE1, OE2 control the three-state outputs. If either enable is high, the output will be in a high impedance state. For data output, both enables must be low. The ACS541MS utilizes advanced CMOS/SOS technology to achieve high-speed operation. This device is a member of the radiation hardened, high-speed, CMOS/SOS logic family. The ACS541MS is supplied in a 20-lead ceramic flatpack (K suffix

Download ACS541KMSR-02 Model

Schematic
symbols

PCB
footprints

3D
models

Symbol

click to zoom

PCB Footprints

ACS541KMSR-02 - Renesas Electronics PCB footprint - Ceramic Dual-In-Line Packages - Ceramic Dual-In-Line Packages - F20.3

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for ACS541KMSR-02
Part Number ACS541KMSR-02
Manufacturer Renesas Electronics
Pin Count 20
Part Category Integrated Circuit
Package Category Ceramic Dual-In-Line Packages
Footprint Name Ceramic Dual-In-Line Packages - F20.3
Released Date Nov 29, 2019
Last Modified Date Oct 24, 2023 7:30 PM UTC
Pinout / Pin List Click Here (Member Only)

ACS541KMSR-02 Details

Manufacturer Part Number:
ACS541KMSR-02
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

ACS541KMSR-02 Overview

Use the download button to access the ACS541KMSR-02 schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like ACS54, or try a keyword search, such as Bus Driver/Transceivers
