ACS716KLATR-12CB-T - Allegro Microsystems

ACS716KLATR-12CB-T Details

• Manufacturer Part Number:

  ACS716KLATR-12CB-T

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  SOIC-16

• Manufacturer:

  Allegro MicroSystems LLC

• YTEOL:

  3

• Additional Feature:

  IT HAS A SENSITIVITY OF 37.1 MV/A

• Body Breadth:

  7.5 mm

• Body Height:

  2.65 mm

• Body Length or Diameter:

  10.3 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e3

• Linearity (%):

  0.75 %

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  16

• Operating Current-Max:

  11 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Type:

  ANALOG VOLTAGE

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP16,.4

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Surface Mount:

  YES

• Technology:

  BICMOS

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER
