AD1555APZ - Analog Devices

Description: AD1555APZ, 24 bit ADC Differential,, Serial, 28-Pin PLCC

Download AD1555APZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AD1555APZ - Analog Devices PCB footprint - Plastic Leaded Chip Carrier - Plastic Leaded Chip Carrier - P-28A(PLCC)
click to zoom
3D Models
AD1555APZ - Analog Devices  - 3D model - Plastic Leaded Chip Carrier - P-28A(PLCC)
click to zoom

AD1555APZ Details

  • Manufacturer Part Number:

    AD1555APZ

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    End Of Life

  • Part Package Code:

    QLCC

  • Package Description:

    PLASTIC, LCC-28

  • Pin Count:

    28

  • Manufacturer Package Code:

    P-28

  • Reach Compliance Code:

    compliant

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • Risk Rank:

    8.47

  • YTEOL:

    .4

  • Analog IC - Other Type:

    ANALOG CIRCUIT
