AD1816AJS - Analog Devices

Description: Stereo Audio Interface 16 b DSP, I²S, Parallel, SPI 100-PQFP (20x14)

Download AD1816AJS Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AD1816AJS - Analog Devices - PCB symbol
click to zoom
PCB Footprints
AD1816AJS - Analog Devices PCB footprint - Quad Flat Packages - Quad Flat Packages - 100-Lead Plastic Quad Flatpack (S-100)
click to zoom
3D Models
AD1816AJS - Analog Devices - 3D model - Quad Flat Packages - 100-Lead Plastic Quad Flatpack (S-100)
click to zoom

AD1816AJS Details

  • Manufacturer Part Number:

    AD1816AJS

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    QFP

  • Package Description:

    PLASTIC, QFP-100

  • Pin Count:

    100

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • JESD-30 Code:

    R-PQFP-G100

  • JESD-609 Code:

    e0

  • Length:

    20 mm

  • Number of Functions:

    1

  • Number of Terminals:

    100

  • Operating Temperature-Max:

    70 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    QFP

  • Package Equivalence Code:

    QFP100,.7X.9

  • Package Shape:

    RECTANGULAR

  • Package Style:

    FLATPACK

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    2.45 mm

  • Supply Current-Max:

    221 mA

  • Supply Voltage-Max (Vsup):

    5.25 V

  • Supply Voltage-Min (Vsup):

    4.75 V

  • Surface Mount:

    YES

  • Temperature Grade:

    COMMERCIAL

  • Terminal Finish:

    TIN LEAD

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    QUAD

  • Width:

    14 mm

AD1816AJS Frequently Asked Questions (FAQs)

  • The recommended power-up sequence is to apply VCC first, followed by VEE, and then the input signals. This ensures proper device operation and prevents latch-up.
  • To minimize noise and EMI, use a multi-layer PCB with a solid ground plane, keep the input and output traces short and separate, and use decoupling capacitors close to the device. Additionally, avoid running high-frequency signals near the device.
  • The AD1816AJS can operate from -40°C to +85°C, but the device's performance may degrade at extreme temperatures. Ensure proper thermal management and consider derating the device for high-temperature applications.
  • While the AD1816AJS is a high-performance device, it may not meet the specific requirements for high-reliability or aerospace applications. Consult with Analog Devices Inc. or a qualified representative to determine the device's suitability for such applications.
  • To troubleshoot issues, start by verifying the power supply and input signal integrity. Check for proper decoupling, ensure the device is properly terminated, and review the layout for potential noise coupling paths. Consult the datasheet and application notes for additional guidance.
