AD210JN - Analog Devices

AD210JN Details

• Manufacturer Part Number:

  AD210JN

• Source Url Status Check Date:

  2013-05-01 14:56:09.034

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  1 X 2.100 INCH, 0.350 INCH HEIGHT, LOW PROFILE, DIP-12

• Pin Count:

  12

• Manufacturer Package Code:

  N-12

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Amplifier Type:

  ISOLATION AMPLIFIER

• Bandwidth (3dB)-Nom:

  15 MHz

• Common Mode Voltage-Max:

  2000 V

• Isolation Voltage-Min:

  1500 V

• JESD-30 Code:

  R-PDIP-T12

• Length:

  53.3 mm

• Neg Supply Voltage-Nom (Vsup):

  -15 V

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP12/38,.8

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  8.91 mm

• Supply Current-Max:

  50 mA

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Voltage Gain-Max:

  100

• Voltage Gain-Min:

  1

• Width:

  25.4 mm
