AD532SH/883B - Analog Devices

AD532SH/883B Details

• Manufacturer Part Number:

  AD532SH/883B

• Source Url Status Check Date:

  2013-05-01 14:56:12.241

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Part Life Cycle Code:

  Not Recommended

• Part Package Code:

  SMT

• Package Description:

  TO-100, 10 PIN

• Pin Count:

  10

• Manufacturer Package Code:

  H-10-1

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  3

• Analog IC - Other Type:

  ANALOG MULTIPLIER OR DIVIDER

• Bandwidth-Nom:

  1 MHz

• JESD-30 Code:

  O-MBCY-W10

• JESD-609 Code:

  e0

• Neg Supply Voltage-Max (Vsup):

  -22 V

• Neg Supply Voltage-Min (Vsup):

  -10 V

• Neg Supply Voltage-Nom (Vsup):

  -15 V

• Negative Input Voltage-Max:

  -10 V

• Number of Functions:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  METAL

• Package Code:

  TO-100

• Package Equivalence Code:

  CAN10,.23

• Package Shape:

  ROUND

• Package Style:

  CYLINDRICAL

• Positive Input Voltage-Max:

  10 V

• Qualification Status:

  Not Qualified

• Screening Level:

  MIL-STD-883 Class B

• Supply Current-Max (Isup):

  6 mA

• Supply Voltage-Max (Vsup):

  22 V

• Supply Voltage-Min (Vsup):

  10 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  WIRE

• Terminal Position:

  BOTTOM
