AD5544SRS-EP - Analog Devices

AD5544SRS-EP Details

• Manufacturer Part Number:

  AD5544SRS-EP

• Source Url Status Check Date:

  2013-05-01 14:56:13.403

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SSOP

• Package Description:

  MO-150-AH, SSOP, 28 PIN

• Pin Count:

  28

• Manufacturer Package Code:

  RS-28

• ECCN Code:

  3A001.a.2.c

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  R-PDSO-G28

• Length:

  10.2 mm

• Linearity Error-Max (EL):

  0.0023%

• Number of Bits:

  16

• Number of Functions:

  4

• Number of Terminals:

  28

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  SSOP28,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Seated Height-Max:

  2 mm

• Settling Time-Nom (tstl):

  0.9 µs

• Supply Current-Max:

  0.009 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  MILITARY

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  5.3 mm
