AD5570WRS - Analog Devices

Description: Digital to Analog Converters - DAC IC 16-bit +/-15V Serial

Download AD5570WRS Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AD5570WRS - Analog Devices PCB footprint - Small Outline Packages - Small Outline Packages - RS-16 (SSOP)
click to zoom
3D Models
AD5570WRS - Analog Devices  - 3D model - Small Outline Packages - RS-16 (SSOP)
click to zoom

AD5570WRS Details

  • Manufacturer Part Number:

    AD5570WRS

  • Source Url Status Check Date:

    2013-05-01 14:56:13.622

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SSOP

  • Package Description:

    PLASTIC, MO-150AC, SSOP-16

  • Pin Count:

    16

  • Manufacturer Package Code:

    RS-16

  • HTS Code:

    8542.39.00.40

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Analog Output Voltage-Max:

    14 V

  • Analog Output Voltage-Min:

    -14 V

  • Converter Type:

    D/A CONVERTER

  • Input Bit Code:

    BINARY

  • Input Format:

    SERIAL

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e0

  • Length:

    6.2 mm

  • Linearity Error-Max (EL):

    0.0031%

  • Moisture Sensitivity Level:

    1

  • Negative Supply Voltage-Nom:

    -12 V

  • Number of Bits:

    16

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SSOP

  • Package Equivalence Code:

    SSOP16,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    240

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    2 mm

  • Settling Time-Max:

    13 µs

  • Settling Time-Nom (tstl):

    12 µs

  • Supply Current-Max:

    5 mA

  • Supply Voltage-Nom:

    12 V

  • Surface Mount:

    YES

  • Technology:

    BICMOS

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    TIN LEAD

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    5.3 mm

AD5570WRS Frequently Asked Questions (FAQs)

  • The AD5570WRS is a high-precision device, and its performance can be affected by the PCB layout and component placement. It is recommended to follow a star-grounding scheme, keep the analog and digital grounds separate, and place the device close to the analog signal sources. Additionally, it is recommended to use a solid ground plane and to avoid running digital signals near the analog signals.
  • To ensure accurate temperature measurement, it is recommended to use a thermistor with a high accuracy and stability, such as a 1% or 0.5% tolerance thermistor. Additionally, the thermistor should be placed close to the device being measured, and the AD5570WRS should be calibrated using a known temperature reference point. It is also important to consider the self-heating effect of the AD5570WRS and to use a low-power mode or a heat sink if necessary.
  • The maximum cable length for the AD5570WRS's analog output depends on the specific application and the noise environment. In general, it is recommended to keep the cable length as short as possible to minimize noise pickup and signal degradation. A cable length of up to 10 feet (3 meters) is typically acceptable, but longer cables may require additional signal conditioning or shielding.
  • The AD5570WRS is specified to operate from a 2.7V to 5.5V power supply, but it is not recommended to operate it at 5V. Operating the device at 5V may cause excessive power consumption and heat generation, which can affect its accuracy and reliability. It is recommended to operate the device at a voltage close to its nominal value of 3.3V.
  • To troubleshoot issues with the AD5570WRS, it is recommended to follow a systematic approach. First, verify that the device is properly powered and that the input signals are within the specified range. Then, check the device's output signals using an oscilloscope or a multimeter. If the issue persists, check the PCB layout and component placement, and verify that the device is properly calibrated. If the issue still persists, contact Analog Devices' technical support for further assistance.
