AD7247JNZ - Analog Devices

Description: AD7247JNZ, 12 bit-Bit DAC Dual, Parallel, 24-Pin PDIP

Download AD7247JNZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AD7247JNZ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
AD7247JNZ - Analog Devices PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - N-24-1
click to zoom
3D Models
AD7247JNZ - Analog Devices - 3D model - Dual-In-Line Packages - N-24-1
click to zoom

AD7247JNZ Details

  • Manufacturer Part Number:

    AD7247JNZ

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP

  • Package Description:

    0.300 INCH, PLASTIC, DIP-24

  • Pin Count:

    24

  • Manufacturer Package Code:

    N-24-1

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog Output Voltage-Max:

    5 V

  • Analog Output Voltage-Min:

    -5 V

  • Converter Type:

    D/A CONVERTER

  • Input Bit Code:

    BINARY

  • Input Format:

    PARALLEL, WORD

  • JESD-30 Code:

    R-PDIP-T24

  • JESD-609 Code:

    e3

  • Length:

    31.165 mm

  • Linearity Error-Max (EL):

    0.024%

  • Negative Supply Voltage-Nom:

    -12 V

  • Number of Bits:

    12

  • Number of Functions:

    2

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP24,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    4.82 mm

  • Settling Time-Max:

    10 µs

  • Settling Time-Nom (tstl):

    5 µs

  • Supply Voltage-Nom:

    12 V

  • Surface Mount:

    NO

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

AD7247JNZ Frequently Asked Questions (FAQs)

  • It is recommended to place the AD7247JNZ close to the analog signal sources, use a solid ground plane, and keep the analog and digital signal traces separate to minimize noise. Additionally, use a low-ESR capacitor for the VCC pin and a 0.1uF capacitor for the AVCC pin.
  • The AD7247JNZ has an internal calibration circuit that can be enabled by setting the CAL pin high. It is recommended to perform a self-calibration cycle after power-up and before taking measurements. The calibration cycle takes approximately 100ms.
  • The maximum sampling rate of the AD7247JNZ is 100kSPS. The power consumption increases with the sampling rate, but the device is designed to operate at low power consumption even at high sampling rates. The typical power consumption at 100kSPS is around 15mW.
  • The AD7247JNZ can be interfaced with a microcontroller using a serial peripheral interface (SPI) or an inter-integrated circuit (I2C) bus. The device supports both 3-wire and 4-wire SPI modes, as well as I2C fast mode and fast mode plus.
  • The AD7247JNZ operates over a temperature range of -40°C to +125°C. The device's performance may vary with temperature, but it is designed to maintain its accuracy and linearity over the entire operating temperature range.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

AD7247JNZ Overview

Use the download button to access the AD7247JNZ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AD724, or try a keyword search, such as Digital to Analog Converters
