AD7376AN1M - Rochester Electronics

AD7376AN1M Details

• Manufacturer Part Number:

  AD7376AN1M

• Pbfree Code:

  No

• Rohs Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  DIP

• Package Description:

  DIP,

• Pin Count:

  14

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Additional Feature:

  REST 3 RESISTOR ARRAY VALUES ARE : 10000,50000,100000 OHMS

• Bandwidth-Nom:

  0.6 kHz

• Control Interface:

  3-WIRE SERIAL

• Converter Type:

  DIGITAL POTENTIOMETER

• JESD-30 Code:

  R-PDIP-T14

• JESD-609 Code:

  e0

• Length:

  19.305 mm

• Moisture Sensitivity Level:

  NOT APPLICABLE

• Negative Supply Voltage-Nom:

  -4.5 V

• Number of Positions:

  128

• Number of Terminals:

  14

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  COMMERCIAL

• Resistance Law:

  LINEAR

• Seated Height-Max:

  5.33 mm

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Resistance-Nom:

  1000000 Ω

• Width:

  7.62 mm
