A low-impedance, single-point ground plane is recommended. Keep the input and output traces short and away from each other to minimize crosstalk. Use a solid ground plane under the device to reduce electromagnetic interference (EMI).
Use the gain equation provided in the datasheet to calculate the required resistor values. Consider the desired gain, input impedance, and output impedance when selecting the resistors. You can also use Analog Devices' online gain calculator tool to simplify the process.
The AD8180ARZ can drive up to 100 pF of capacitive load. Exceeding this limit can cause instability and oscillations. To ensure stability, add a series resistor (Rs) to the output to isolate the capacitive load and prevent oscillations.
Use a low-pass filter (LPF) or a band-pass filter (BPF) in conjunction with the AD8180ARZ to filter out high-frequency noise and EMI. You can also add a ferrite bead or a common-mode choke to the power supply lines to reduce EMI.
Use a combination of ceramic and electrolytic capacitors to decouple the power supply. Place a 10 μF ceramic capacitor and a 10 μF electrolytic capacitor in parallel, as close to the device as possible. Add a 0.1 μF ceramic capacitor in parallel with the power supply lines to filter out high-frequency noise.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AD8180ARZ Overview
Use the download button to access the AD8180ARZ schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AD818,
