ADCMP573BCP-R2 - Analog Devices

ADCMP573BCP-R2 Details

• Manufacturer Part Number:

  ADCMP573BCP-R2

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFN

• Package Description:

  3 X 3 MM, MO-220-VEED-2, LFCSP-16

• Pin Count:

  16

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Amplifier Type:

  COMPARATOR

• Bias Current-Max (IIB) @25C:

  50 µA

• Input Offset Voltage-Max:

  5000 µV

• JESD-30 Code:

  S-XQCC-N16

• JESD-609 Code:

  e0

• Length:

  3 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC16,.12SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  Not Qualified

• Response Time-Nom:

  0.165 ns

• Seated Height-Max:

  1 mm

• Supply Current-Max:

  80 mA

• Supply Voltage Limit-Max:

  6 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Lead (Sn85Pb15)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  3 mm
