- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for ADG742BKSZ5-REEL7
- Part Number ADG742BKSZ5-REEL7
- Manufacturer Analog Devices
- Pin Count 5
- Part Category Integrated Circuit
- Package Category SOT23 (5-Pin)
- Footprint Name SOT23 (5-Pin) - ADG742BKSZ5-REEL7
- Released Date Jan 11, 2017
- Last Modified Date Nov 15, 2024 1:35 PM UTC
- Pinout / Pin List Click Here (Member Only)
ADG742BKSZ5-REEL7 Details
-
Manufacturer Part Number:
ADG742BKSZ5-REEL7
-
Brand Name:
Analog Devices Inc
-
Pbfree Code:
No
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Part Package Code:
TSSOT
-
Package Description:
LEAD FREE, MO-203AA, SC-70, 5 PIN
-
Pin Count:
5
-
Manufacturer Package Code:
KS-6
-
Country Of Origin:
Malaysia
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.01
ADG742BKSZ5-REEL7 Frequently Asked Questions (FAQs)
-
A good PCB layout for the ADG742BKSZ5-REEL7 involves keeping the analog and digital grounds separate, using a solid ground plane, and minimizing the length of the signal traces. Additionally, placing the device close to the analog signal sources and using shielding or guard rings around the analog signals can help reduce EMI and noise.
-
To ensure proper powering and decoupling of the ADG742BKSZ5-REEL7, use a low-ESR capacitor (e.g., 0.1 μF) between the VDD and GND pins, and a larger capacitor (e.g., 10 μF) between the VDD and GND pins for bulk decoupling. Also, ensure that the power supply is clean and well-regulated, and that the device is operated within its recommended operating voltage range.
-
The ADG742BKSZ5-REEL7 is a high-speed analog switch with a maximum operating frequency of up to 200 MHz. However, the actual operating frequency may be limited by the specific application, PCB layout, and signal integrity considerations.
-
The ADG742BKSZ5-REEL7 has a maximum junction temperature of 150°C. To ensure proper thermal management, use a heat sink or thermal pad on the device, and ensure good airflow around the device. Additionally, minimize the power dissipation of the device by optimizing the operating conditions and reducing the voltage supply.
-
The recommended soldering profile for the ADG742BKSZ5-REEL7 involves a peak temperature of 240°C, with a dwell time of 10-30 seconds above 217°C. The device should be soldered using a reflow soldering process, and the soldering iron should be set to a temperature of 350°C.
Trust Checks
Community Provided
System Verified
Community Approved
ADG742BKSZ5-REEL7 Overview
Use the download button to access the ADG742BKSZ5-REEL7 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADG74,
or try a keyword search, such as Multiplexers or Switches
