ADG901SCPZ-EP - Analog Devices

ADG901SCPZ-EP Details

• Manufacturer Part Number:

  ADG901SCPZ-EP

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LFCSP-8

• Pin Count:

  8

• Manufacturer Package Code:

  CP-8-13

• Country Of Origin:

  South Korea

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  10

• 1dB Compression Point:

  17 dBm

• Additional Feature:

  CMOS COMPATIBLE

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  18 dBm

• Insertion Loss-Max:

  1.25 dB

• Isolation-Min:

  31 dB

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• On Time-Nom:

  0.004 µs

• Operating Frequency-Max:

  1000 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC8,.12,20

• Port Termination:

  ABSORPTIVE

• Power Supplies:

  1.65/2.75 V

• RF/Microwave Device Type:

  SPST

• Supply Current-Max:

  70 mA

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• VSWR-Max:

  1.08
