ADH1300-48S28B-6LI - Advanced Energy

ADH1300-48S28B-6LI Details

• Manufacturer Part Number:

  ADH1300-48S28B-6LI

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, EN, IEC, TUV, UL

• Efficiency (Main Output):

  95.5%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P16

• Length:

  61 mm

• Line Regulation-Max:

  0.178%

• Load Regulation-Max:

  0.07142%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  46.5 A

• Output Voltage-Max:

  32.984 V

• Output Voltage-Min:

  14 V

• Output Voltage-Nom:

  28 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,16LEAD,1.9

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.17675 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  12.9 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1300 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  1.3 s

• Width:

  57.9 mm
