ADIS16201CCCZ - Analog Devices

Description: Programmable Dual-Axis Inclinometer/Accelerometer

Download ADIS16201CCCZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADIS16201CCCZ - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADIS16201CCCZ - Analog Devices PCB footprint - Other - Other - ADIS16201CCCZ-2
click to zoom
3D Models
ADIS16201CCCZ - Analog Devices - 3D model - Other - ADIS16201CCCZ-2
click to zoom

ADIS16201CCCZ Details

  • Manufacturer Part Number:

    ADIS16201CCCZ

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    LGA

  • Package Description:

    LGA-16

  • Pin Count:

    16

  • Manufacturer Package Code:

    CC-16-2

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    10

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-XBGA-N16

  • JESD-609 Code:

    e4

  • Length:

    9.2 mm

  • Moisture Sensitivity Level:

    5

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    LGA

  • Package Equivalence Code:

    LGA16,4X4,70

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    3.9 mm

  • Supply Voltage-Max (Vsup):

    3.6 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Gold (Au)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    1.78 mm

  • Terminal Position:

    BOTTOM

  • Width:

    9.2 mm
