ADL5504ACBZ-P2 - Analog Devices

ADL5504ACBZ-P2 Details

• Manufacturer Part Number:

  ADL5504ACBZ-P2

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  1.20 X 0.80 MM, ROHS COMPLIANT, CB-6-8, WLCSP-6

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• JESD-609 Code:

  e1

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  6000 MHz

• Operating Frequency-Min:

  450 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Polarity:

  POSITIVE

• Power Supplies:

  3 V

• RF/Microwave Device Type:

  LINEAR DETECTOR

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)
