ADL5504ACBZ-P7 Details

  • Manufacturer Part Number:

    ADL5504ACBZ-P7

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    1.20 X 0.80 MM, ROHS COMPLIANT, CB-6-8, WLCSP-6

  • Pin Count:

    6

  • Manufacturer Package Code:

    CB-6-8

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • JESD-609 Code:

    e1

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    6000 MHz

  • Operating Frequency-Min:

    450 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Polarity:

    POSITIVE

  • Power Supplies:

    3 V

  • RF/Microwave Device Type:

    LINEAR DETECTOR

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

ADL5504ACBZ-P7 Frequently Asked Questions (FAQs)

  • A good PCB layout for the ADL5504ACBZ-P7 involves keeping the input and output traces short and away from each other, using a solid ground plane, and placing decoupling capacitors close to the device. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is recommended.
  • To ensure proper biasing, make sure to connect the VPOS pin to a stable voltage source between 4.5V and 5.5V, and the VNEG pin to a stable voltage source between -4.5V and -5.5V. Also, ensure that the input common-mode voltage is within the recommended range of 1.5V to 3.5V.
  • The maximum input signal amplitude that the ADL5504ACBZ-P7 can handle is ±1.4V peak-to-peak. Exceeding this limit may result in distortion or damage to the device.
  • The output voltage of the ADL5504ACBZ-P7 is a linear representation of the input power level. The output voltage range is 0V to 3.3V, with 0V indicating minimum input power and 3.3V indicating maximum input power.
  • The response time of the ADL5504ACBZ-P7 to changes in input power is typically around 10µs. This means that the device can track changes in input power levels within 10µs.
