ADL5571ACPZ-R7 - Analog Devices

ADL5571ACPZ-R7 Details

• Manufacturer Part Number:

  ADL5571ACPZ-R7

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  4 X 4 MM, ROHS COMPLIANT, LFCSP-16

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  0

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  29 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Frequency-Max:

  2700 MHz

• Operating Frequency-Min:

  2500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC16,.16SQ,25

• Power Supplies:

  3.5/5 V

• RF/Microwave Device Type:

  NARROW BAND MEDIUM POWER

• Surface Mount:

  YES

• Technology:

  GAAS

• Terminal Finish:

  Matte Tin (Sn)

• VSWR-Max:

  10
