ADL6012ACPZN-R7 - Analog Devices

ADL6012ACPZN-R7 Details

• Manufacturer Part Number:

  ADL6012ACPZN-R7

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LFCSP-10

• Pin Count:

  10

• Manufacturer Package Code:

  CP-10-12

• ECCN Code:

  5A991.B

• HTS Code:

  8542.39.00.01

• Date Of Intro:

  2020-05-19

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  20 dBm

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  10

• Operating Frequency-Max:

  67000 MHz

• Operating Frequency-Min:

  2000 MHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Polarity:

  POSITIVE

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC10,.08,20

• Power Supplies:

  5 V

• RF/Microwave Device Type:

  LINEAR DETECTOR

• Supply Current-Max:

  31.7 mA

• Surface Mount:

  YES

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• VSWR-Max:

  1.92
