ADL8121ACPZN - Analog Devices

Description: RF Amp Single LNA 12GHz 6V 6-Pin LFCSP EP T/R

Download ADL8121ACPZN Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ADL8121ACPZN - Analog Devices PCB footprint - Small Outline No-lead - Small Outline No-lead - 2 mm × 2 mm Body and 0.85 mm Package Height (CP-6-12)_2021
click to zoom
3D Models
ADL8121ACPZN - Analog Devices  - 3D model - Small Outline No-lead - 2 mm × 2 mm Body and 0.85 mm Package Height (CP-6-12)_2021
click to zoom

ADL8121ACPZN Details

  • Manufacturer Part Number:

    ADL8121ACPZN

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Pin Count:

    6

  • Manufacturer Package Code:

    CP-6-12

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    8.5

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    15 dB

  • Input Power-Max (CW):

    32 dBm

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    12000 MHz

  • Operating Frequency-Min:

    25 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Equivalence Code:

    SOLCC6,.08,25

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER

  • Surface Mount:

    YES

  • Technology:

    PHEMT

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • VSWR-Max:

    1.43

ADL8121ACPZN Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output traces short and away from each other to minimize noise coupling.
  • Ensure the input voltage is within the recommended range (2.7V to 5.5V) and the output voltage is set to the desired level using the FB pin. Also, ensure the EN pin is properly biased to enable the device.
  • The maximum input voltage is 5.5V, exceeding this may cause damage to the device. It's recommended to use a voltage regulator or a voltage limiter to prevent overvoltage conditions.
  • Check the PCB layout for noise coupling, ensure proper decoupling capacitors are used, and verify the input and output voltage levels are within the recommended range. Also, check for any signs of overheating or physical damage to the device.
  • The ADL8121ACPZN is rated for operation up to 125°C, but it's recommended to derate the device's performance at high temperatures. Ensure proper thermal management and consider using a heat sink if necessary.
