ADMX3652Z-ML Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  A 4-layer PCB with a solid ground plane and a separate analog ground plane is recommended. Keep the analog and digital grounds separate and connected only at the ADMX3652Z-ML. Use short, direct traces for the analog signals and avoid crossing digital signals over the analog signals.
• How do I ensure accurate temperature measurement?
  Use a thermocouple or RTD sensor with a high accuracy rating. Ensure proper sensor calibration and compensation for non-linearity. Use a low-noise, low-impedance connection to the sensor. Avoid self-heating of the sensor and the ADMX3652Z-ML.
• What is the maximum cable length for the sensor interface?
  The maximum cable length depends on the sensor type, cable quality, and noise environment. As a general guideline, keep the cable length below 10 meters for thermocouples and 5 meters for RTDs. Use shielded cables and twisted pairs to minimize noise pickup.
• How do I handle electromagnetic interference (EMI) and radio-frequency interference (RFI)?
  Use a metal enclosure for the ADMX3652Z-ML and ensure good grounding. Use EMI filters or ferrite beads on the power supply lines. Keep the analog and digital circuits separated and use shielding or guard rings around the analog signals.
• What is the recommended power supply decoupling?
  Use a 10 μF ceramic capacitor and a 1 μF film capacitor in parallel, placed close to the ADMX3652Z-ML power pins. Add a 100 nF capacitor between the analog and digital power pins to reduce noise coupling.
