ADP3302AR4 Details

• Manufacturer Part Number:

  ADP3302AR4

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOIC

• Package Description:

  SOP,

• Pin Count:

  8

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Dropout Voltage1-Max:

  0.2 V

• Dropout Voltage2-Max:

  0.2 V

• Input Voltage-Max:

  12 V

• Input Voltage-Min:

  3.6 V

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.9 mm

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  8

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -55 °C

• Output Current1-Max:

  0.1 A

• Output Current2-Max:

  0.1 A

• Output Voltage1-Max:

  3.347 V

• Output Voltage1-Min:

  3.253 V

• Output Voltage1-Nom:

  3.3 V

• Output Voltage2-Max:

  5.07 V

• Output Voltage2-Min:

  4.93 V

• Output Voltage2-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  COMMERCIAL

• Regulator Type:

  FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.75 mm

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  3.9 mm
