ADPM12160CMLZDL - Analog Devices

ADPM12160CMLZDL Details

• Manufacturer Part Number:

  ADPM12160CMLZDL

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/4 BRICK PACKAGE-14

• ECCN Code:

  EAR99

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN; CSA; EN; IEC; UL

• Efficiency (Main Output):

  97.5%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  40 V

• Input Voltage-Nom:

  54 V

• JESD-30 Code:

  R-XDMA-X14

• Length:

  58.4 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  133.3 A

• Output Voltage-Max:

  12.12 V

• Output Voltage-Min:

  11.88 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Packing Method:

  TRAY

• Protections:

  OVER CURRENT; OVER VOLTAGE; SHORT CIRCUIT; THERMAL

• Ripple Voltage (Main Out):

  0.05 Vrms

• Screening Level:

  CSA/EN/IEC/UL 62368-1; IEC 60068-2-27

• Seated Height-Max:

  15.8 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1600 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.345 s

• Width:

  36.8 mm
