ADSP-2111KG-66 - Rochester Electronics

ADSP-2111KG-66 Details

• Manufacturer Part Number:

  ADSP-2111KG-66

• Brand Name:

  Analog

• Pbfree Code:

  No

• Rohs Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  PGA

• Package Description:

  CERAMIC, PGA-100

• Pin Count:

  100

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Additional Feature:

  20 MIPS; 8/16 BIT PARALLEL HOST INTERFACE PORT; SINGLE CYCLE INSTRUCTION EXECUTION

• Address Bus Width:

  14

• Barrel Shifter:

  YES

• Boundary Scan:

  NO

• Clock Frequency-Max:

  16.67 MHz

• External Data Bus Width:

  24

• Format:

  FIXED POINT

• Internal Bus Architecture:

  MULTIPLE

• JESD-30 Code:

  S-CPGA-P100

• JESD-609 Code:

  e0

• Length:

  33.53 mm

• Low Power Mode:

  YES

• Number of Terminals:

  100

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  PGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  COMMERCIAL

• Seated Height-Max:

  4.29 mm

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  PERPENDICULAR

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  33.53 mm

• uPs/uCs/Peripheral ICs Type:

  DIGITAL SIGNAL PROCESSOR, OTHER
