ADSP-BF518BBCZ4F16 - Analog Devices

Description: Analog Devices ADSP-BF518BBCZ4F16, 16/32bit Blackfin Digital Signal Processor 400MHz 116 kB Flash 168-Pin CSP BGA

Download ADSP-BF518BBCZ4F16 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADSP-BF518BBCZ4F16 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADSP-BF518BBCZ4F16 - Analog Devices PCB footprint - BGA - BGA - 168-Ball CSP_BGA
click to zoom
3D Models
ADSP-BF518BBCZ4F16 - Analog Devices - 3D model - BGA - 168-Ball CSP_BGA
click to zoom

ADSP-BF518BBCZ4F16 Details

  • Manufacturer Part Number:

    ADSP-BF518BBCZ4F16

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Pin Count:

    168

  • Manufacturer Package Code:

    BC-168-1

  • HTS Code:

    8542.31.00.35

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • JESD-609 Code:

    e1

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Technology:

    CMOS

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Time@Peak Reflow Temperature-Max (s):

    30

  • uPs/uCs/Peripheral ICs Type:

    DIGITAL SIGNAL PROCESSOR, OTHER

ADSP-BF518BBCZ4F16 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the ADSP-BF518BBCZ4F16 is -40°C to 85°C.
  • The external memory interface on the ADSP-BF518BBCZ4F16 can be configured using the External Bus Interface Unit (EBIU) registers. Refer to the ADSP-BF518BBCZ4F16 datasheet and the Blackfin Processor Programming Reference manual for more information.
  • The maximum clock frequency supported by the ADSP-BF518BBCZ4F16 is 400 MHz.
  • The DMA controller on the ADSP-BF518BBCZ4F16 can be used to transfer data between peripherals and memory. Refer to the ADSP-BF518BBCZ4F16 datasheet and the Blackfin Processor Programming Reference manual for more information on configuring and using the DMA controller.
  • The power consumption of the ADSP-BF518BBCZ4F16 varies depending on the operating frequency and voltage. Refer to the ADSP-BF518BBCZ4F16 datasheet for more information on power consumption.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ADSP-BF518BBCZ4F16 Overview

Use the download button to access the ADSP-BF518BBCZ4F16 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ADSP-, or try a keyword search, such as Digital Signal Processors
