ADSP-TS201SABPZ050 - Analog Devices

Description: ADSP-TS201SABPZ050 Analog Devices TigerSHARC, 32bit DSP 500MHz 16 MB EPROM 576-Pin BGA

Download ADSP-TS201SABPZ050 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ADSP-TS201SABPZ050 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
ADSP-TS201SABPZ050 - Analog Devices PCB footprint - BGA - BGA - BP-576---
click to zoom
3D Models
ADSP-TS201SABPZ050 - Analog Devices - 3D model - BGA - BP-576---
click to zoom

ADSP-TS201SABPZ050 Details

  • Manufacturer Part Number:

    ADSP-TS201SABPZ050

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    BGA

  • Package Description:

    25 X 25 MM, MS-034, BGA-576

  • Pin Count:

    576

  • Manufacturer Package Code:

    BP-576

  • ECCN Code:

    3A991.a.2

  • HTS Code:

    8542.31.00.35

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Additional Feature:

    ALSO REQUIRES 2.5V SUPPLY

  • Address Bus Width:

    32

  • Barrel Shifter:

    YES

  • Bit Size:

    32

  • Boundary Scan:

    YES

  • Clock Frequency-Max:

    125 MHz

  • External Data Bus Width:

    64

  • Format:

    FLOATING POINT

  • Internal Bus Architecture:

    MULTIPLE

  • JESD-30 Code:

    S-PBGA-B576

  • JESD-609 Code:

    e1

  • Length:

    25 mm

  • Low Power Mode:

    NO

  • Moisture Sensitivity Level:

    3

  • Number of Terminals:

    576

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    BGA

  • Package Equivalence Code:

    BGA576,24X24,40

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    3.1 mm

  • Supply Voltage-Max:

    1.1 V

  • Supply Voltage-Min:

    1 V

  • Supply Voltage-Nom:

    1.05 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    1 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Width:

    25 mm

  • uPs/uCs/Peripheral ICs Type:

    DIGITAL SIGNAL PROCESSOR, OTHER
