ADUM6020-3WBRIZ - Analog Devices

ADUM6020-3WBRIZ Details

• Manufacturer Part Number:

  ADUM6020-3WBRIZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOIC-16

• ECCN Code:

  EAR99

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, EN, UL, CSA, TUV

• Efficiency (Main Output):

  33%

• Input Voltage-Max:

  3.6 V

• Input Voltage-Min:

  3 V

• Input Voltage-Nom:

  3.3 V

• JESD-30 Code:

  R-PDSO-G16

• Length:

  12.75 mm

• Load Regulation-Max:

  5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.07 A

• Output Voltage-Max:

  3.6 V

• Output Voltage-Min:

  3 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP16,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Ripple Voltage (Main Out):

  0.0459 Vrms

• Screening Level:

  AEC-Q100; IEC/EN 62368-1; IEC 61010-1; IEC 60601-1

• Seated Height-Max:

  2.64 mm

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  0.231 W

• Trim/Adjustable Output:

  NO

• Width:

  7.5 mm
