ADVFC32SH - Analog Devices

ADVFC32SH Details

• Manufacturer Part Number:

  ADVFC32SH

• Source Url Status Check Date:

  2013-05-01 14:56:52.015

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Part Life Cycle Code:

  Not Recommended

• Part Package Code:

  SMT

• Package Description:

  TO-100, 10 PIN

• Pin Count:

  10

• Manufacturer Package Code:

  H-10-1

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  3

• Converter Type:

  VOLTAGE TO FREQUENCY CONVERTER

• JESD-30 Code:

  O-MBCY-W10

• JESD-609 Code:

  e0

• Linearity Error-Max (EL):

  0.2%

• Negative Input Voltage-Max:

  -10 V

• Negative Supply Voltage-Max:

  -18 V

• Negative Supply Voltage-Min:

  -9 V

• Negative Supply Voltage-Nom:

  -15 V

• Number of Functions:

  1

• Number of Terminals:

  10

• Operating Frequency-Max:

  0.5 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  METAL

• Package Code:

  TO-100

• Package Equivalence Code:

  CAN10,.23

• Package Shape:

  ROUND

• Package Style:

  CYLINDRICAL

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  8 mA

• Supply Voltage-Max:

  18 V

• Supply Voltage-Min:

  9 V

• Supply Voltage-Nom:

  15 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  WIRE

• Terminal Position:

  BOTTOM
