ADY32006 - Panasonic

ADY32006 Details

• Manufacturer Part Number:

  ADY32006

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  8

• Body Breadth:

  15 mm

• Body Height:

  10 mm

• Body Length or Diameter:

  20 mm

• Coil Current(DC)-Max:

  0.033 A

• Coil Operate Voltage(DC):

  4.2 V

• Coil Power:

  200 mW

• Coil Release Voltage(DC):

  4.2 V

• Coil Resistance:

  180 Ω

• Coil Voltage(DC)-Max:

  6 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  8A@380VAC

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact (DC) Max Rating R Load:

  8A@125VDC

• Contact Voltage(AC)-Max:

  380 V

• Contact Voltage(DC)-Max:

  125 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  20mm x 15mm x 10mm

• Reference Standard:

  CSA; TUV; UL

• Relay Action:

  LATCHED

• Relay Function:

  DPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  8 ms

• Sealing:

  PLASTIC SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER
