CUI recommends a PCB layout with a solid ground plane and thermal vias to dissipate heat. A minimum of 1 oz copper thickness is recommended. For thermal management, ensure good airflow and consider using a heat sink or thermal interface material.
To ensure reliable operation in high-vibration environments, CUI recommends securing the module using screws or adhesive, and using a vibration-dampening material such as silicone or rubber. Additionally, ensure that the PCB is properly secured to the chassis or enclosure.
CUI recommends using low-ESR capacitors with a minimum capacitance of 10uF for the input and output. The capacitor values may vary depending on the specific application and operating conditions. Consult with a CUI engineer for specific recommendations.
Yes, the AE10-EW-S24 can be used in a redundant or parallel configuration. However, it's essential to ensure that the modules are properly synchronized and that the system is designed to handle the increased power and heat dissipation. Consult with a CUI engineer for specific guidance.
The typical lead time for the AE10-EW-S24 is 8-12 weeks, and the minimum order quantity (MOQ) is 500 pieces. However, these may vary depending on the specific configuration, quantity, and availability. Contact CUI's sales team for the most up-to-date information.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AE10-EW-S24 Overview
Use the download button to access the AE10-EW-S24 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AE10-,
or try a keyword search, such as Power Supply Modules
