AFBR-1639Z - Avago Technologies

Description: Fiber Optic Transmitters, Receivers, Transceivers VL V 50MBd TX w. dr. IC inv

Download AFBR-1639Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
3D Models
AFBR-1639Z - Avago Technologies  - 3D model
click to zoom
Note! To download footprints and symbols, use the build and request forms below

Build

Launch Build Wizard
Build Wizard not available for this package category!

Request (48 hours)

AFBR-1639Z Details

  • Manufacturer Part Number:

    AFBR-1639Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Reach Compliance Code:

    Compliant

  • Manufacturer:

    Avago Technologies

  • YTEOL:

    5

  • Additional Feature:

    IT ALSO HAS SUPPLY VOLTAGE 4.75 TO 5.25 V, PCS FIBER TYPE AND OUPUT OPTICAL POWER IS -13 DBM

  • Communication Standard:

    RS-232, RS-485

  • Emitter/Detector Type:

    LED

  • Fiber Optic Device Type:

    TRANSMITTER

  • Fiber Type:

    POF

  • JESD-609 Code:

    e3

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Operating Wavelength-Max:

    685 nm

  • Operating Wavelength-Min:

    630 nm

  • Operating Wavelength-Nom:

    658 nm

  • Optical Power Output-Nom:

    0.63 mW

  • Supply Voltage-Max:

    3.465 V

  • Supply Voltage-Min:

    3.135 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    NO

  • Terminal Finish:

    Tin (Sn)

  • Transmission Type:

    DIGITAL

AFBR-1639Z Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. The device should be placed near the edge of the board to minimize signal reflections. A 50-ohm microstrip transmission line should be used to connect the device to the antenna.
  • The device requires a single 3.3V power supply. A 10uF capacitor should be connected between the VCC pin and ground to filter out noise. A 1kohm resistor should be connected between the VCC pin and the EN pin to enable the device.
  • The device is rated for operation from -40°C to 85°C. However, the optimal operating temperature range is from 0°C to 70°C for maximum performance and reliability.
  • Use a spectrum analyzer to check the transmitted signal spectrum and ensure it meets the required specifications. Check the device's power supply and biasing to ensure they are within the recommended range. Use a logic analyzer to check the device's control signals and ensure they are correct.
  • Yes, the device can be used in a multi-device configuration. However, each device should have its own antenna and be spaced at least 10mm apart to minimize interference. A common power supply and ground plane can be shared among devices.
