AFBR-59R5LZ - Foxconn

AFBR-59R5LZ Details

• Manufacturer Part Number:

  AFBR-59R5LZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT, PACKAGE-14

• ECCN Code:

  5A991.B.5.A

• HTS Code:

  8517.62.00.50

• Manufacturer:

  Foxconn Interconnect Technology Limited

• Body Breadth:

  13.59 mm

• Body Height:

  9.65 mm

• Body Length or Diameter:

  48.1 mm

• Built-in Feature:

  AMPLIFIER

• Communication Standard:

  GBE

• Connection Type:

  LC CONNECTOR

• Data Rate (Rx):

  4250 Mbps

• Data Rate (Tx):

  4250 Mbps

• Emitter/Detector Type:

  LASER DIODE, PIN PHOTODIODE

• Fiber Optic Device Type:

  TRANSCEIVER

• Fiber Type:

  50/125, 62.5/125, MMF

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE MOUNT

• Operating Temperature-Max:

  70 °C

• Operating Wavelength-Max:

  860 nm

• Operating Wavelength-Min:

  830 nm

• Operating Wavelength-Nom:

  845 nm

• Optical Power Output-Nom:

  0.125 mW

• Return Loss-Min:

  12 dB

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)
