AFCT-5961ATLZ - Foxconn

AFCT-5961ATLZ Details

• Manufacturer Part Number:

  AFCT-5961ATLZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Reach Compliance Code:

  Compliant

• ECCN Code:

  5A991.B.5.A

• HTS Code:

  8517.62.00.50

• Manufacturer:

  Foxconn

• Additional Feature:

  2 X 5 ARRAY

• Body Breadth:

  15.2 mm

• Body Height:

  10.2 mm

• Body Length or Diameter:

  49 mm

• Built-in Feature:

  AMPLIFIER

• Communication Standard:

  ATM, GR-253, ITU-T-G.957, OC-3, SDH, SONET, STM-1

• Connection Type:

  LC CONNECTOR

• Data Rate (Rx):

  155 Mbps

• Data Rate (Tx):

  155 Mbps

• Emitter/Detector Type:

  LASER DIODE, PIN PHOTODIODE

• Fiber Optic Device Type:

  TRANSCEIVER

• Fiber Type:

  9/125, SMF

• Mounting Feature:

  BOARD/PANEL MOUNT

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Operating Wavelength-Max:

  1360 nm

• Operating Wavelength-Min:

  1261 nm

• Operating Wavelength-Nom:

  1300 nm

• Optical Power Output-Nom:

  0.07 mW

• Return Loss-Min:

  14 dB

• Sensitivity:

  -38 dBm

• Supply Voltage-Max:

  3.5 V

• Supply Voltage-Min:

  3.1 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  NO
