AFDI00282811100M06 - Yageo Group

AFDI00282811100M06 Details

• Manufacturer Part Number:

  AFDI00282811100M06

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  YAGEO Corporation

• YTEOL:

  8

• Construction:

  Cylindrical

• Core Material:

  POWDERED ALLOY

• DC Resistance:

  0.00364 Ω

• Inductance-Nom (L):

  10 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  1.8 mm

• Lead Length:

  4 mm

• Lead Spacing:

  16 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -50 °C

• Package Diameter:

  28 mm

• Package Length:

  10.5 mm

• Package Style:

  Radial

• Packing Method:

  Bulk

• Rated Current-Max:

  36 A

• Reference Standard:

  AEC-Q200

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  YES

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
