AHES4191 - Panasonic

AHES4191 Details

• Manufacturer Part Number:

  AHES4191

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  6.89

• Body Breadth:

  30 mm

• Body Height:

  40 mm

• Body Length or Diameter:

  36 mm

• Coil Current(DC)-Max:

  0.157 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  1880 mW

• Coil Release Voltage(DC):

  0.6 V

• Coil Resistance:

  76.6 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  1A@277VAC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@30VDC

• Contact Voltage(AC)-Max:

  277 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  30 ms

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  36mm x 30mm x 40mm

• Reference Standard:

  CUL; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  3PST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  MOISTURE PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
