AIF06ZPFC-01NTL - Advanced Energy

AIF06ZPFC-01NTL Details

• Manufacturer Part Number:

  AIF06ZPFC-01NTL

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  FULL BRICK PACKAGE-24

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  28 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  7

• Analog IC - Other Type:

  AC-DC POWER FACTOR CORRECTION MODULE

• Approvals:

  CE, CSA, EN, UL, VDE

• Efficiency (Main Output):

  97%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-XXMA-P24

• Length:

  116.8 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  24

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  403 V

• Output Voltage-Min:

  397 V

• Output Voltage-Nom:

  400 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Equivalence Code:

  MODULE,24LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.0106 Vrms

• Screening Level:

  EN/UL 62368-1

• Seated Height-Max:

  13.95 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  2400 W

• Trim/Adjustable Output:

  YES

• Width:

  61 mm
