AIRD-02-222K Details

Abracon recommends a land pattern with a minimum pad size of 1.3mm x 1.3mm and a non-solder mask defined (NSMD) pad shape to ensure reliable soldering and to prevent solder bridging.
To prevent damage, Abracon recommends following a reflow profile with a peak temperature of 260°C (500°F) and a dwell time of 20-30 seconds. The component should be placed on the PCB with the markings facing upwards.
The AIRD-02-222K is rated for operation from -40°C to +125°C, but it's recommended to derate the frequency and power handling at higher temperatures to ensure reliable operation.
Yes, the AIRD-02-222K is designed to withstand vibrations up to 10G peak acceleration, but it's recommended to follow Abracon's guidelines for vibration testing and to ensure proper PCB mounting and soldering.
Abracon recommends following a systematic troubleshooting approach, starting with visual inspection, then checking the PCB layout and soldering, and finally verifying the component's electrical characteristics using a network analyzer or spectrum analyzer.
