AIRD-06-331K - ABRACON

AIRD-06-331K Details

• Manufacturer Part Number:

  AIRD-06-331K

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Construction:

  Cylindrical

• Core Material:

  FERRITE

• DC Resistance:

  0.305 Ω

• Inductance-Nom (L):

  330 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  1.8 mm

• Lead Length:

  12.5 mm

• Lead Spacing:

  19 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Diameter:

  21 mm

• Package Length:

  21 mm

• Package Style:

  Radial

• Packing Method:

  Bulk

• Quality Factor-Min (at L-nom):

  15

• Rated Current-Max:

  1.6 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.001 MHz

• Tolerance:

  10%
