The recommended PCB layout for optimal thermal performance involves placing thermal vias under the IC, using a solid ground plane, and keeping the thermal traces as short and wide as possible. A 4-layer PCB with a dedicated thermal layer is also recommended.
To ensure the device is properly biased, make sure to follow the recommended voltage and current ratings, and provide a stable input voltage within the specified range. Also, ensure that the output capacitors are properly sized and placed close to the device.
Potential EMI issues with the AL5873T16E-13 include radiated emissions from the switching node and conducted emissions through the input and output lines. To mitigate these issues, use a shielded layout, add EMI filters, and ensure proper grounding and decoupling.
The AL5873T16E-13 is rated for operation up to 125°C, but the device's performance and reliability may degrade at higher temperatures. Ensure that the device is properly derated and that the PCB is designed to handle high temperatures.
Potential failure modes of the AL5873T16E-13 include overvoltage, overcurrent, and overheating. To detect these failure modes, implement overvoltage protection, current sensing, and thermal monitoring. Also, ensure that the device is properly protected against electrical overstress.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AL5873T16E-13 Overview
Use the download button to access the AL5873T16E-13 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AL587,
or try a keyword search, such as Display Drivers
