ALA2F12 - Panasonic

ALA2F12 Details

• Manufacturer Part Number:

  ALA2F12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  0

• Body Breadth:

  12 mm

• Body Height:

  25 mm

• Body Length or Diameter:

  24 mm

• Coil Current(DC)-Max:

  0.044 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  530 mW

• Coil Release Voltage(DC):

  0.6 V

• Coil Resistance:

  272 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  5A@125VAC

• Contact Current(AC)-Max:

  5 A

• Contact Voltage(AC)-Max:

  125 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  50000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  24mm x 12mm x 25mm

• Reference Standard:

  CSA; SEMKO; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  DPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Sealing:

  FLUX FREE SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER
