AME3-5SBJZ - aimtec

AME3-5SBJZ Details

• Manufacturer Part Number:

  AME3-5SBJZ

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  Module-4

• ECCN Code:

  EAR99

• Manufacturer:

  Aimtec

• YTEOL:

  0

• Additional Feature:

  ALSO AVAILABLE WITH 100 TO 745 V DC INPUT VOLTAGE; FOR 90 TO 165 INPUT TEMP. MIN IS -20

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  528 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-PDMA-P4

• Length:

  50.8 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage-Max:

  5.25 V

• Output Voltage-Min:

  4.75 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  15.66 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  2.5 W

• Trim/Adjustable Output:

  NO

• Width:

  25.4 mm
